CRUCES CON REDUCCIÓN A 45º

CRUCES REDUCCION 45 AIR GALVA AIRTUB GALVANIZADOS HELICOIDALES

CRUCES CON REDUCCIÓN A 45º

-Descripción:
Cruces con Reducción a 45º construidas a partir de 3 piezas  ( tubo principal  e injertos a 45º perpendiculares entre ellos a 180º) El diametro de los injertos siempre sera inferior al tubo principal.

-Material:
Acero galvanizado con recubrimiento de zinc Z-200/ Z-275 de espesores 0.5,0.6,0.8 y 1 mm según el diámetro

-Diámetros Disponibles:
Desde Ø 80 hasta Ø 1600

-Tipo de unión:
Enchufable (Accesorios Macho y Tubos Hembra en ambas bocas ) Union mediante Tornillos autotaladrantes o remaches.

-Opciones:
Se puedan fabricar cruces con diferentes grados de inclinación en el injerto, variar el angulo entre injertos, diámetros a medida y modificar longitudes tanto en el tubo principal como en los injertos. Posibilidad de acabado M/H ,unión con Brida tipo “Metu”, brida plana (2/3 mm), tapa final e incluso malla electrosoldada.

Categorías:

A Continuación les indicamos los PVP. Si lo desea puede descargarse la pagina en pdf.

Ficha Técnica Codo 30º

Ficha Técnica Cruces con Reducción a 45º

Catálogo PDF Airtub

Tarifa Cruces con Reducción a 45º



Ø8010012515016017520022525027530031535040045050055060063065070075080085090095010001050110011501200125013001400
10015,288
12516,1417,472
15017,30418,6622,452
16018,04820,5823,95225,992
17518,7822,48825,4428,05630,168
20019,99222,69228,24830,07232,30434,512
22520,24425,53631,23635,92836,56437,238,652
25021,64829,56834,10436,13238,20840,2642,27646,32
27526,44835,42436,13239,15640,2641,37646,3250,25650,964
30030,1835,92837,64440,46442,945,31249,04450,55654,08459,124
31532,2836,63640,16443,58445,31247,02849,45251,46857,73260,45665,4
35033,34837,64441,37645,21646,63248,03650,35255,71658,82464,78870,33272,96
40036,13239,40842,57647,02848,03649,04451,46856,80864,78870,4472,55276,70484,612
45037,23642,1845,62449,65650,11250,55658,82463,7866,40870,78876,51283,95297,692115,248
50038,65243,18847,6450,5254,22857,93661,76465,90470,69277,30485,0896,924105,144125,436144,6
55041,37645,62448,74451,67254,80457,93665,80871,65277,5284,97296,48105,36124,32143,076155,004179,928
60045,21647,9451,46859,12462,06464,99270,1476,51284,55295,76106,572116,856138,048151,272157,728180,936189,516
63060,38463,4266,45672,51680,2892,136102,972111,216127,452142,344154,452167,568184,92197,7215,856
65061,64464,7467,82474,8884,04899,708110,184115,848138,048146,616157,632177,408188,916205,86234,012243,792
70082,53699,096110,688115,968137,04143,076151,152176,808190,32221,184231,9243,996253,584263,16
750106,572120,288133,404142,572161,352172,752184,836217,776227,664245,52261,516271,656283,92296,184299,4
800131,328142,488160,344172,56187,908212,916228,372243,408256,524267,528279,84292,128302,628331,2
850142,272157,632171,36190,92212,916231,288243,192253,488264,6288294,972301,92323,112333,6346,836
900179,832213,924231,9245,436253,488263,376280,344302,532312,684322,824333,6349,464366,528402,432
950210,9223,008245,436255,408263,376278,724301,02322,32329,28336,252349,356366,528398,808411,12438,264
1000252,168256,416264,168285,9311,916327,108336,672346,236365,52393,348413,136433,128447,84466,224
1050330,78340,848350,916379,14405,456426,456447,096465,048485,052514,38
1100334,44345,012355,584392,748417,576439,776461,064482,256503,868543,72556,932
1150339,684355,056370,44404,16426,252448,908468,288490,98517,44553,104570,156591,036
1200344,928365,112385,296415,572434,94458,04475,5499,704531562,476587,208611,928642,216
1250381,648400,62419,592438,768458,352477,624502,728531,096556,836609,108626,772644,424672,48700,536
1300404,856421,008437,16458,94477,624499,62531,6556,836610,32644,04673,104702,144749,076796,008888,84
1400425,064437,172449,268468,132487,512531,708556,224615,372640,788705,384746,856788,328836,064883,8912,036954,228
1500443,208452,892462,576480,648508,704563,28614,76672,384745,944816,576839,712862,824888,648914,472954,4321037,3761094,568
1600472,752483,072493,416512,688542,616600,84655,752717,204795,672871,008895,68920,352947,892975,4441018,0681106,5441167,54
