CRUCES CON REDUCCIÓN A 90º INOXIDABLES

-Descripción:
Cruces con Reducción a 90º construidas a partir de 3 piezas  ( tubo principal  e injertos a 90º perpendiculares entre ellos a 180º) El diametro de los injertos siempre sera inferior al tubo principal.

-Material:
Acero Inoxidable AISI 304-2B de espesor 0.5 y 0.6 mm según el diámetro

-Diámetros Disponibles:
Desde Ø 80 hasta Ø 1600

-Tipo de unión:
Enchufable (Accesorios Macho y Tubos Hembra en ambas bocas ) Union mediante Tornillos autotaladrantes o remaches.

-Opciones:
Se puedan fabricar cruces con diferentes grados de inclinación en el injerto, variar el angulo entre injertos, diámetros a medida y modificar longitudes tanto en el tubo principal como en los injertos. Posibilidad de acabado M/H ,unión con Brida tipo “Metu”, brida plana (2/3 mm), tapa final e incluso malla electrosoldada.

Categorías:

A Continuación les indicamos los PVP. Si lo desea puede descargarse la pagina en pdf.

Ficha Técnica Codo 30º

Ficha Técnica Cruces con Reducción a 90º Inox

Catálogo PDF Airtub

Tarifa Cruces con Reducción a 90º Inoxidables



Ø10012515016017520022525027530031535040045050055060063065070075080085090095010001050110011501200125013001400
10033,576
12535,352
15038,60444,796
16039,46845,50426,256
17540,3246,21252,555,44
20041,61648,44454,99658,39261,776
22549,47655,561,53666,7687279,2
25052,10458,90862,32867,5672,79284,57694,896
27552,89659,17265,17271,59278,02488,48897,644101,82
30055,64463,3678,26480,11281,94891,092100,272105,12115,704
31558,11671,48481,15683,92886,67695,304104,184110,496119,928122,532
35059,55675,39681,94887,04892,148101,82109,296119,928128,94138,228151,32
40064,93277,24486,91692,54498,184107,34117,288128,028135,624151,32156,576170,94
45068,84481,94891,09296,852102,612110,496121,224131,448144,516156,024163,092181,944216,78
50072,91289,0498,976104,208109,44120,96127,74138,228152,364162,84174,876191,652223,188241,392
55081,15694,764104,736113,244121,74134,052147,384160,488183,792201,084232,764244,524258,924263,1290,604
600112,044123,312134,568140,736153,804171,732194,256219,384237,732252,912260,496275,676291,9313,632
630135,624143,016163,032183208,128227,76243,492255,792262,596280,392364,56334,584358,8
650136,656145,296172,272194,256221,988236,148249,252258,672264,684285,108437,232355,536383,016396,408
700181,164198,432231,18238,236251,856259,98284,316296,364329,34362,208392,316409,8427,26
750187,98223,056238,236251,616259,704284,052296,364327,756339,828364,956417,588441,528465,48512,856
800235,776253,428272,808290,604312,6330,408342,948365,472392,184434,076455,928477,792523,08563,388
850261,552287,472312,06330,12342,948366,024391,392434,076477,264499,392521,508563,388597,96616,02
900292,68330,408345,072366,024391,392429,888474,396518,904537,288555,672583,284602,784642,588683,292
950300,3336,156366,024391,392430,128486,432515,868555,264569,28583,284602,688641,94657,132706,224750,072
1000362,868391,392440,616486,432513,648555,264580,68591,684602,688642,972659,22693,78730,668758,58794,58
1050526,74559,32581,988592,332602,688642,972659,22700,056745,212775,272844,152898,428
1100539,832563,388583,284592,992602,688642,972659,22706,332759,744791,94893,724952,7041000,644
1150570,984593,112607,968622,824661,704711,576749,532826,5868,188947,881007,8081048,5841082,172
1200578,58602,928622,956642,972680,448763,932792,732893,244944,4361002,0361062,9121089,3481115,7841151,268
1250642,972670,476697,968738,012898,26894,828944,4361001,9281057,681122,6121147,7521172,881186,7521.200,61
1300735,684790,128904,8952,4281001,9281067,4841134,9241172,221197,2881.222,361.260,061.297,741.347,62
1400905,316945,0841007,6881060,8361135,9441167,121.220,771.251,291.281,791.311,431.341,071.405,081.462,96
15001017,8761064,2321144,5961165,5481.212,921.272,891.314,261.355,621.381,011.406,391.453,761.501,22
16001085,7361135,1761.220,901.243,251.293,781.357,751.401,861.445,991.473,071.500,141.550,681.601,301.700,94
